3mm discrete LED in red color, 25PCs / Package, works fine on Rainbowduino extension shield.
Specifications
- Maximum Forward Current: 30mA
- Maximum Reverse Voltage: 6V
- Forward Voltage: 1.9V~2.6V (IF=20mA)
- Reverse Current: 5uA
- Luminous Intensity: 30~50mcd (IF=20mA)
- Viewing Angel: 30deg
- Wavelength: 568~573nm
- Working Temperature: -55~+100°C
- Storage Temperature: -55~+100°C
- Soldering Temperature: 260°C for 5 seconds
