Features
- Powerful MCU Board: Incorporate the ESP32S3 32-bit, dual-core, Xtensa processor running at up to 240MHz, mounted multiple development ports, Arduino / MicroPython supported
- Outstanding RF performance: Supports 2.4GHz WiFi and BLE 5.0 dual wireless communication, supports 100m+ remote communication when connected with U.FL antenna
- Elaborate Power Design: Lithium battery charge management capability, offers 4 power consumption model which allows for deep sleep mode with power consumption as low as 14μA
- Thumb-sized Compact Design: 21 x 17.5mm, adopting the classic form factor of XIAO, suitable for space limited projects like wearable devices
- Perfect for Production: Breadboard-friendly & SMD design, no components on the back
Note
XIAO SoM User Manual open-sources all hardware and software materials of XIAO, providing professional product design guidelines to help you accelerate ideas off the ground, streamline product design, providing a seamless experience from module selection to mass production. You can check here to see more info.
We already have 8 XIAO MCUs based on popular chipsets of SAMD21, nRF52840, ESP32-C3, ESP32-S3, and ESP32-C6. To help you better understand the differences and choose the most suitable one for your projects, pleasev visit the Seeed Studio XIAO Series Page.
Specification
|
Parameter |
Seeed Studio XIAO ESP32S3 |
|
|
Processor |
ESP32-S3R8 |
ESP32-C3 SoC |
|
Xtensa LX7 dual-core, 32-bit processor running up to 240 MHz |
RISC-V single-core 32-bit chip processor with a four-stage pipeline that operates at up to 160 MHz |
|
|
Wireless |
Complete 2.4GHz WiFi subsystem |
|
|
BLE: Bluetooth 5.0, Bluetooth mesh |
||
|
On-chip Memory |
8M PSRAM & 8MB Flash |
400KB SRAM & 4MB Flash |
|
Interface |
1x UART, 1x IIC, 1x IIS, 1x SPI,11x GPIO(PWM), 9x ADC, 1x User LED, 1x Charge LED |
1x UART, 1x IIC, 1x SPI,11x GPIO(PWM), 4x ADC |
|
1x Reset button, 1x Boot button |
||
|
Dimensions |
21 x 17.5mm |
|
|
Power |
Input voltage (Type-C): 5V Input voltage (BAT): 4.2V |
Input voltage (Type-C): 5V Input voltage (BAT): 4.2V |
|
Circuit operating Voltage (ready to operate): – Type-C: 5V@19mA – BAT: 3.8V@22mA |
Circuit operating Voltage (ready to operate): – USB:5V@9mA – BAT:3.8V@9mA |
|
|
Charging battery current: 100mA |
Charging battery current: 350mA |
|
|
Low Power Consumption Model (Supply Power: 3.8V) |
Modem-sleep Model: ~ 25 mA Light-sleep Model: ~ 2mA Deep Sleep Model: ~ 14 μA |
Modem-sleep Model: ~ 24 mA Light-sleep Model: ~ 3 mA Deep Sleep Model: ~ 44 μA |
|
WiFi Enabled Power Consumption |
Active Model: ~ 100 mA |
Active Model: <75 mA |
|
BLE Enabled Power Consumption |
Active Model: ~ 85 mA |
Modem-sleep Model: <27 mA |
|
Working Temperature |
-40°C ~ 65°C |
-40°C ~ 85°C |
Hardware overview
- Onboard
- PinOut
Application
- Internet of Things
- Wearable devices
- Smart Homes
- Robotics
- Health Monitoring
- Education
- Low-Power(LP) networking
- Rapid prototyping
