Features
- Pocket-size Module: compact at 70mm x45mm
- Big Compute Performance: it delivers 472 GFLOPs(0.5 TFLOPs) AI performance, featuring a 128-core Maxwell architecture GPU and a Quad-core ARM CPU, which can run multiple neural networks in parallel and processes high-resolution sensors concurrently.
- Low Power Demands: high-performance computing at just 5-10 watts.
- Efficient AI Development with NVIDIA JetPack™ SDK: supports the entire NVIDIA Software Stack for application development and optimization.
- Flexible Customization: Integrate the production-grade module seamlessly into your full systems, which are empowered by our customizable ODM services to meet the specific hardware needs for device makers and integrators, including form factor adjustments, image flashing, and logo customizations.
Specification
|
AI Performance |
Jetson Nano 4GB – 0.5 TFLOPS |
|
GPU |
128-core NVIDIA Maxwell™ GPU |
|
CPU |
Quad-core ARM A57 @ 1.43 GHz |
|
Memory |
4 GB 64-bit LPDDR4 25.6 GB/s |
|
Storage |
16 GB eMMC 5.1 |
|
Video Encoder |
1x 4K30 (H.265) | 2x 1080p60 (H.265) |
|
Video Decoder |
1x 4K30 (H.265) | 2x 1080p60 (H.265) |
|
Camera |
Up to 4 cameras, 12 lanes MIPI CSI-2, D-PHY 1.1 (up to 18 Gbps) |
|
Power Consumption |
5-10W |
|
Dimensions (W x D) |
69.6mm x 45mm |
Application
Application Fields:
- AI Video Analytics
- Machine Vision
- Autonomous Mobile Robot (AMR)
